Cestari 9000L v1.0

DESCRIPTION

Weight
1,400kg on wheels

Capacity
9,000 liters without black roll tarp crest

Maximum Load
7.500 kg

Discharge Auger
304mm (12 ") diameter auger with a discharge rate up to 4 ton per minute. Fitted with hydraulic raise & lower.

Unloading Time
Approximately 4 minutes

Discharge Height
Discharge Height 4,300mm under spout

Unloading
Upper Side, power take off - Mid side, power take off - Lower manual (by gravity)

Discharge Auger Cover
Hydraulic ram controlled shut off slide covers auger flight Allowing am to be unloaded at any speed

Hydraulics
Requires one pair of hydraulics for the hydraulic folding auger

Axles
Wide wing 140mm x 140mm I Beam fitted with heavy duty 8 stud hubs

Wheels
DW16x30 8 Stud Rims

Tyres
23.1 x 30 12 Ply Lug Type Tractor Tyres

PTO Shaft
Telescopic Shaft PTO with safety covers and shear pin to prevent breakage

Gear Box
Heavy duty gearbox with forged steel and oil coated gears

Recommended Tractor
40 to 60 H / P Tractor on firm ground 60 to 80 H / P Tractor on soft ground

Cleanout
Fitted with simple cleanout door fitted to the bottom of the bin

Signs and Lights
Fitted with oversize sign and revolving light.

Roll Tarp
Fitted complete with Heavy Duty Roll Top Tarp.

Work Light
Work light mounted by the discharge spout

Sight Glass
Sight glass fitted to the front of the bin

Ladders
Fitted with a front external ladder

Optional Scales
Electronic scales with .05% accuracy can be fitted as an option. Two weigh cells under the axle and one in between the tow hitch and the bin.


Optional Folding Chute
Electronically controlled folding chute on end-of-discharge auger

Optional Quad View Monitor with 3 cameras
Optional 9 am "quad view monitor with 3 camera's mounted on the bin, one on the end of the discharge chute, one inside the am and one at the rear of the

CREDITS

Model: Bautista Ojeda
Textures: Bautista Ojeda
Ls15: Pl_teams and fix
